200KW 270HP Big Power screw silent stationary air compressor price list (SCR270II)
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location: None
Condition: New
Type: Screw
Configuration: Stationary
Power Source: AC POWER
Lubrication Style: Lubricated
Mute: Yes
Voltage: 380(400,415)V/50Hz/3Phase, 220V/60HZ/3P
Dimension(L*W*H): 2700*1820*1850mm
Weight: 4000kg
Warranty: 1 Year
Working Pressure: Other
Machinery Test Report: Not Available
Video outgoing-inspection: Not Available
Marketing Type: Other
Warranty of core components: Other
Core Components: Other
Gas Type: Air
After-sales Service Provided: Overseas service center available
Color: Blue
Power(KW): 200
Capacity(m3/min): 727 m3/H
Presssure(BAR): 7
Compressed air outlet: 65-110 m3/MIN
HP: 270
Speed type: Fixed speed
Protection Grade: IP 54
Operating Ambient Temp: 1-45℃ {28.8℉-120℉}
Applicable Industries: Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works, Energy & Mining, Food & Beverage Shops, Advertising Company
Showroom Location: None
Warranty: 1 Year
Working Pressure: Other
Machinery Test Report: Not Available
Video outgoing-inspection: Not Available
Marketing Type: Other
Warranty of core components: Other
Core Components: Other
Gas Type: Air
Condition: New
Type: Screw
Configuration: Stationary
Power Source: AC POWER
Lubrication Style: Lubricated
Mute: Yes
Voltage: 380(400,415)V/50Hz/3Phase, 220V/60HZ/3P
Dimension(L*W*H): 2700*1820*1850mm
Weight: 4000kg
After-sales Service Provided: Overseas service center available
Color: Blue
Power(KW): 200
Capacity(m3/min): 727 m3/H
Presssure(BAR): 7
Compressed air outlet: 65-110 m3/MIN
HP: 270
Speed type: Fixed speed
Protection Grade: IP 54
Operating Ambient Temp: 1-45℃ {28.8℉-120℉}
Packaging Details: Plywood case or carton case suitable for long sea transportation
Port: Shanghai Port
| Model | KW | HP | Capacity | Pressure | Dimension(mm) | Weight | Size |
| SCR125II-7 | 90 | 125 | 16.5 | 7 | 2460*1620*1692 | 2560 | DN65 |
| SCR125II-8 | 16 | 8 | |||||
| SCR125II-10 | 14.5 | 10 | |||||
| SCR125II-12.5 | 12.5 | 12.5 | |||||
| SCR150II-7 | 110 | 150 | 20.3 | 7 | 2460*1620*1692 | 2560 | DN65 |
| SCR150II-8 | 20 | 8 | |||||
| SCR150II-10 | 17.5 | 10 | |||||
| SCR150II-12.5 | 15.6 | 12.5 | |||||
| SCR180II-7 | 132 | 180 | 24.5 | 7 | 2700*1750*1850 | 3100 | DN65 |
| SCR180II-8 | 24 | 8 | |||||
| SCR180II-10 | 21 | 10 | |||||
| SCR180II-12.5 | 18 | 12.5 | |||||
| SCR220II-7 | 160 | 220 | 29 | 7 | 2700*1750*1850 | 3200 | DN65 |
| SCR220II-8 | 28.3 | 8 | |||||
| SCR220II-10 | 24 | 10 | |||||
| SCR220II-12.5 | 21.5 | 12.5 | |||||
| SCR250II-7 | 185 | 250 | 32.5 | 7 | 2700*1750*1850 | 3450 | DN80 |
| SCR250II-8 | 31.6 | 8 | |||||
| SCR250II-10 | 28.3 | 10 | |||||
| SCR250II-12.5 | 24.5 | 12.5 | |||||
| SCR270II-7 | 200 | 270 | 35.1 | 7 | 2700*1750*1850 | 3640 | DN80 |
| SCR270II-8 | 34.5 | 8 | |||||
| SCR270II-10 | 30.8 | 10 | |||||
| SCR270II-12.5 | 27.8 | 12.5 |
Product Quick Detail:
- 标准和非标准
- With high quality and competitive price
- Prompt delivery
- Packing as per customer’s demand.
We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.
Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.
Materials Available
1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
Surface Treatment
Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.
Processing Method
CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
QC & Certificate
Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009
Package & Lead Time
Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
