WD110/ WDH110 Chain Sprockets

WD110 Sprocket

Welded steel chains have numerous uses. They are strong enough to handle heavy loads. They are durable enough to withstand harsh conditions and can last for years. In addition, they are easy to install and provide a secure mounting point. However, you must be sure to follow a few safety precautions when installing them.

The following are some useful tips:Welded steel chains are offset-sidebar construction. They do not include rollers. Their strong construction makes them ideal for abrasive and high-impact conveying applications. They are also easy to adjust and modify. With its many uses, welded steel chains are the industry's top choice.

The WD110 sprockets work with WD110 and WDH110 welded steel tow chains. This WD110 sprocket is manufactured using high quality steel and precise specifications to ensure optimum performance and long service life. We can supply this sprocket in standard or flanged configuration.

Sprocket Number	Pitch	Number of Teeth	Pitch Diameter	Maximum Bore	Shroud Diameter	Tooth Face
WD110-6	6.00"	6	12.00"	4-7/16"	8.892"	9.00"
WD110-7	6.00"	7	13.83"	4-7/16"	10.98"	9.00"
WD110-8	6.00"	8	15.68"	5-15/16"	12.99"	9.00"
WD110-9	6.00"	9	17.54"	5-15/16"	14.99"	9.00"
WD110-10	6.00"	10	19.42"	5-15/16"	16.968"	9.00"
WD110-11	6.00"	11	21.30"	5-15/16"	18.92"	9.00"

We aslo offer a full range of both precisionroller chainand engineered.
