Rotary Cutter Mower Gearbox Manufacturers

synchromesh gearbox construction and working38265562748

Description: 40 HP Rotary cutter gearbox with 1-3/8″ smooth input shaft and a gear ratio of 1:1.47. Cast iron housing is sealed to protect the gears and bearings. The mounting plate has four bolt holes spaced 4.75″ square. Ships without oil (16 oz of 80-90 W) Gearbox has a piloted…

Category:Agricultural Gearbox

Get a Free Quote

Description

40 HP Rotary cutter gearbox with 1-3/8" smooth input shaft and a gear ratio of 1:1.47. Cast iron housing is sealed to protect the gears and bearings. The mounting plate has four bolt holes spaced 4.75" square. Ships without oil (16 oz of 80-90 W)

The gearbox has a piloted flange bottom to fit a 5-1/4" pilot hole in the mower/cutter deck.

Bolt Pattern:	4-3/4" Square with holes for 5/8" bolt
Pilot Hole Size:	5-1/4"
Input Shaft:	1-3/8" Smooth with 1/2 Shear-hole
Output Shaft:	1-9/16" Tapered 12-spline
Input Power Max:	40 HP
Input Speed:	540/1000 RPM
Shaft Rotation:	CCW to CW with 1:1.47 Ratio

Application:

Replaces OEM gearboxes on 4', 5', and some 6' rotary cutters by these manufacturers， Please check measurements for proper fitment.

Technical Information:

Hot Tags: rotary mower gearbox, China, suppliers, manufacturers, factory, wholesale, buy, made in China

Product Quick Detail:

Standard and non-standard available
高质量和有竞争力的价格
Prompt delivery
Packing as per customer’s demand.

We promise will offer the best price by the high quality in china! We also accept special order about the products. If you are interested in our products. Please do not hesitate to let us know.We are pleased to give you the detailed information.We promise that our products would be safety and were in high quality and reasonable price. If you are interested in our products, please contact us asap.We are sincerely looking for your cooperation.

Most of our products are exported to Europe or Americas, both standard and nonstandard products available. We can produce as per your drawing or sample. Material can be standard or as per your special request. If you choose us, you choose reliable.

pruduct quality report

Materials Available

1. Stainless Steel: SS201, SS303, SS304, SS316, SS416, SS420
2. Steel:C45(K1045), C46(K1046),C20
3. Brass:C36000 ( C26800), C37700 ( HPb59), C38500( HPb58), C27200(CuZn37), C28000(CuZn40)
4. Bronze: C51000, C52100, C54400, etc
5. Iron: 1213, 12L14,1215
6. Aluminum: Al6061, Al6063
7.OEM according to your request
product materials available

Surface Treatment

Annealing, natural canonization, heat treatment, polishing, nickel plating, chrome plating, zinc plating,yellow passivization, gold passivization, satin, Black surface painted etc.

Processing Method

CNC machining, punch,turning, milling, drilling, grinding, broaching, welding and assembly
product finishing

QC & Certificate

Technicians self-check in production,final-check before package by professional Quality inspector
ISO9001:2008 , ISO14001:2001,ISO/TS 16949:2009

Package & Lead Time

Size: Drawings
Wooden Case/Container and pallet, or as per customized specifications.
15-25days samples. 30-45days offcial order
Port: Shanghai/Ningbo port
product packages
